ECR (Container Registry)
Store and serve container images from Spinifex's AWS-compatible ECR: create a repository, authenticate Docker, push and pull images, and let EKS workers pull.
Overview
ECR on Spinifex serves a private container registry on the Spinifex gateway endpoint — the same host:9999 you already use for the AWS API. Authentication is account-scoped by token, so you push and pull at the gateway host and never need extra DNS:
<spinifex-gateway-host>:9999/<repository>
aws ecr describe-repositories and aws ecr get-login-password return the exact host to use — always prefer that value. Where real DNS is configured, the AWS-parity per-account host <account-id>.dkr.ecr.<region>.<your-spinifex-domain>:9999 also works.
Each repository holds image manifests and their layers. Images are stored in object storage (Predastore) in a per-account bucket, with blobs content-addressed and de-duplicated across repositories. Authentication is token-based: aws ecr get-login-password mints a short-lived bearer token that docker login uses against the registry's /v2/ endpoint.
What works today
- Repository lifecycle —
CreateRepository,DeleteRepository,DescribeRepositories. - OCI push and pull — blobs, manifests, and tags, including cross-repository blob mounts.
- OCI 1.1 referrers — the referrers API, so cosign v3 signatures and other artifacts attached to an image can be listed (see OCI referrers and image signing).
- Token auth —
GetAuthorizationTokenplus bearer/basic auth on/v2/. A token is valid for 12 hours. One minted by an assumed-role session (an EKS node, for example) stays valid after that session expires and is checked against the live role on every request, so it stops working when the role is deleted or loses its ECR permissions. - Repository policies — set, get, and delete a repository policy document.
Current limitations
- Image scanning is not supported — scan APIs return an explicit "operation not supported" error.
- No automatic garbage collection yet — deleting images does not yet reclaim underlying blobs.
- Lifecycle-policy enforcement and tag-immutability enforcement are not active.
Prerequisites
- Spinifex running, with the AWS CLI configured for the
spinifexprofile (see Installing Spinifex). - Docker installed locally to build, push, and pull images.
- Docker trusting the Spinifex CA. The registry serves TLS signed by the Spinifex local CA. Install it into the host trust store once (Docker uses the host root pool for registry TLS, so this covers every account endpoint without per-host config):
sudo cp /etc/spinifex/ca.pem /usr/local/share/ca-certificates/spinifex-local-ca.crt
sudo update-ca-certificates
sudo systemctl restart docker
This reaches dockerd and anything running directly on the host. A tool that runs in its own container, or a buildx builder using the docker-container driver, has a separate trust store; see Troubleshooting.
- The registry endpoint — the Spinifex gateway
host:9999.aws ecr get-login-passwordandaws ecr describe-repositoriesreturn the exacthost:port; copy it from there rather than constructing it by hand. - For EKS pulls: worker nodes need the
AmazonEC2ContainerRegistryReadOnlypolicy on their node IAM role (the EKS prerequisites already include this) and network egress to the registry endpoint.
Instructions
Create a repository and push an image using your preferred tool.
1. Create a repository
export AWS_PROFILE=spinifex
aws ecr create-repository --repository-name my-app
aws ecr describe-repositories --repository-names my-app \
--query 'repositories[0].repositoryUri'
The repositoryUri is the value you tag and push to — the gateway host:9999 with the repository path, port included (for example 192.0.2.10:9999/my-app). Use it verbatim; don't hand-build a hostname.
2. Authenticate Docker
Take the registry host straight from the API so the :9999 port is correct:
REGISTRY=$(aws ecr describe-repositories --repository-names my-app \
--query 'repositories[0].repositoryUri' --output text | cut -d/ -f1)
aws ecr get-login-password --region <region> \
| docker login --username AWS --password-stdin "$REGISTRY"
3. Build, tag, and push
docker build -t my-app:latest .
docker tag my-app:latest "$REGISTRY/my-app:latest"
docker push "$REGISTRY/my-app:latest"
4. Verify and pull
aws ecr describe-images --repository-name my-app
docker pull "$REGISTRY/my-app:latest"
EKS workers and multiple gateways
Each gateway puts its own address in the repositoryUri it returns, so repositories created through different gateways can carry different hosts. When an EKS worker launches, the daemon that launches it writes every cluster gateway into the worker's registry mirrors, TLS trust and credential-provider config. A pod can then pull from any repositoryUri host in the cluster. The worker tries the gateway named in the image reference first and falls back to the others in cluster order.
Limits:
- The gateway list comes from the cluster config the launching daemon loaded at start.
A gateway added later is not trusted by existing workers; restart the launching daemon and replace the worker.
- Peer gateways are assumed to listen on port 9999.
A hand-edited awsgw bind on a peer is not covered.
- A gateway address that does not answer costs about 30 seconds on each cold pull while the worker's connection attempt gives up.
A stopped gateway on a host that is still up refuses the connection, and the worker moves to the next gateway at once.
Measured on a single-node environment: pulls by repositoryUri and by the account's ECR DNS name, a pull rejected with x509: certificate signed by unknown authority when the gateway host was not in the worker config, and a 31 second pull through an unreachable first endpoint. Measured on a 3-node environment: a pod pulling each of the three gateways' repositoryUri on a worker launched with this change (two of the three failed with x509 on a worker launched without it), and a pull of the stopped gateway's own repositoryUri that succeeded through another gateway within one retry (the pull itself took 147 ms after the first endpoint refused).
OCI referrers and image signing
A manifest can name another manifest as its subject, which is how tools such as cosign v3 attach signatures and SBOMs to an image. The registry records the subject when the manifest is pushed and answers with an OCI-Subject header on the 201. The subject does not have to exist in the repository when the referrer is pushed.
GET /v2/<name>/referrers/<digest> lists the manifests that name <digest> as their subject. The request is authorised as ecr:BatchGetImage on the repository. The response is 200 with Content-Type: application/vnd.oci.image.index.v1+json and an index whose manifests hold each referrer's mediaType, digest, size, artifactType and annotations. A digest with no referrers, or one that is not stored, returns an empty index. A malformed digest returns 400 with DIGEST_INVALID.
Adding ?artifactType=<type> returns only referrers of that type and sets OCI-Filters-Applied: artifactType. The header is also set when nothing matches. An image manifest without an artifactType is listed under its config mediaType; an index without one has none.
Deleting an image by digest (DELETE /v2/<name>/manifests/<digest>, aws ecr batch-delete-image with imageDigest) also deletes its referrers, and their referrers in turn. Deleting by tag removes only the tag and leaves the image and its referrers.
cosign v3 sign and verify work against the registry, including on a child manifest of an image index copied with cosign copy. cosign v2 keeps writing its sha256-<digest>.sig tags and is unaffected. GET on a manifest still returns 406 when the request's Accept header does not include the stored mediaType.
Limits:
cosign copydoes not copy v3 signatures to the destination repository.
This is client behaviour. To keep the original signature, copy with oras cp -r <source> <mirror>, which copies the image and its referrers in one command, or crane copy the signature manifest by digest after the image. Otherwise, sign the copy again.
- Referrers pushed before this version are not listed.
Push them again to add them to the index.
- A crash between deleting an image and deleting its referrers can leave referrers behind that nothing lists.
- The referrers listing is not paginated.
HEADon the referrers route is not served.
Measured on a 3-node environment with cosign v3.1.4 and v2.6.5:
- cosign v3.1.4 signed a fresh image index, with one
GET /referrersanswered200, nosha256-<digest>tag written and no406. - Verify passed.
- A copied index's child manifest signed and verified, which returned
406before this change. - The listing returned the signature with its
artifactType, the filter returned one entry for the signature's type and none for another type. aws ecr batch-delete-imageof the signed image left an empty listing and404for both the signature and the image.- cosign v2.6.5 signed and verified a fresh image.
Not measured: oras, notation, a listing with many referrers, and a crash in the middle of a delete.
Troubleshooting
docker login fails with an authorization error. The token is account-scoped and short-lived. Re-run aws ecr get-login-password to mint a fresh token, and confirm the registry host in docker login matches your account's endpoint (aws ecr describe-repositories returns it).
docker push cannot reach the registry. Use the exact host from aws ecr describe-repositories — the Spinifex gateway host:9999. Docker dials it directly, so the :9999 port must be present (without it docker tries :443 and fails). If you are using the AWS-parity <account-id>.dkr.ecr… hostname instead, that path needs DNS resolving it to the gateway — prefer the gateway host the API returns.
A containerised tool fails with x509: certificate signed by unknown authority, while docker login and docker push work from the host. The registry token exchange (POST /v2/token) runs in the process that issued the build or push. When that process is itself a container, such as ghcr.io/basecamp/kamal or a containerised CI runner, it checks the registry certificate against the container's trust store, which does not hold the Spinifex CA. Bind-mount the host bundle, which already includes the CA after update-ca-certificates, over the container's bundle:
docker run --rm -it \
-v /etc/ssl/certs/ca-certificates.crt:/etc/ssl/certs/ca-certificates.crt:ro \
-v /var/run/docker.sock:/var/run/docker.sock \
-v "$PWD:/workdir" \
ghcr.io/basecamp/kamal:latest deploy
Mounting the whole bundle keeps the public roots, so pulls of public base images still verify. Pointing SSL_CERT_FILE at ca.pem alone replaces them and breaks those pulls.
docker buildx build --push fails with an x509 error, while docker push of the same image works. The buildx driver decides whose trust store BuildKit uses. The docker driver runs the BuildKit built into dockerd, which uses the host trust store, so the host CA install above covers it. The docker-container driver, the default for a builder made with docker buildx create, runs BuildKit in its own container, and a CA installed on the host or mounted into the CLI container does not reach it.
Use the docker driver when you can (docker buildx use default, or builder: driver: docker in Kamal's config/deploy.yml). The docker-container route is unavoidable for multi-platform builds and remote builders, which the docker driver cannot do. For those, give BuildKit the CA through its own config:
# buildkitd.toml
[registry."<spinifex-gateway-host>:9999"]
ca = ["/etc/spinifex/ca.pem"]
docker buildx create --name spinifex --driver docker-container \
--buildkitd-config buildkitd.toml --use
docker buildx create copies the referenced CA file into the builder container, so recreate the builder after a CA rotation.
EKS workers cannot pull an image. Confirm the node IAM role has AmazonEC2ContainerRegistryReadOnly and that the workers have egress to the registry endpoint (an Internet Gateway or NAT Gateway route). See the EKS prerequisites.
Image-scanning commands return an error. Image scanning is not supported on Spinifex; the scan APIs intentionally reject these calls. Remove scan-on-push configuration from your tooling.
A pushed image still appears after deletion frees no space. Garbage collection of unreferenced blobs is not yet automatic — deleting an image removes its manifest and tags but does not immediately reclaim the underlying layers.
